Pushing Your Docker Image to AWS ECR

Introduction

Before deploying ECS Fargate, you need to store your Docker image in AWS ECR (Elastic Container Registry). This guide covers ECR setup, Docker authentication, and the exact commands to push your image—all in 10 minutes.

What You'll Learn:

• ✅ Create ECR repository (Terraform + AWS Console)

• ✅ Authenticate Docker with AWS CLI

• ✅ Build and tag your Docker image correctly

• ✅ Push image to ECR (with error troubleshooting)

• ✅ Configure ECS to pull from ECR

1. Create ECR Repository

Option A: AWS Console (Quick)

1. Go to AWS Console → ECR

2. Click "Create repository"

3. Name: "ecs-app-repository"

4. Tag visibility: "Public" (for development)

5. Click "Create repository"

Option B: Terraform (Production)

resource "aws_ecr_repository" "app" {
  name                 = "ecs-app-repository"
  image_tag_mutability = "MUTABLE"

  image_scanning_configuration {
    scan_on_push = true
  }

  tags = {
    Name = "ecs-app-ecr"
  }
}

# Optional: Lifecycle policy (delete old images)
resource "aws_ecr_lifecycle_policy" "app" {
  repository = aws_ecr_repository.app.name

  policy = jsonencode({
    rules = [
      {
        rulePriority = 1
        description  = "Delete images older than 30 days"
        selection    = {
          tagStatus     = "any"
          countType     = "sinceImagePushed"
          countUnit     = "days"
          countNumber   = 30
        }
        action = {
          type = "expire"
        }
      }
    ]
  })
}

Deploy:

terraform apply

Expected Cost:

• ECR: $0.10/GB/month storage

• First 500MB: Free (AWS free tier)

2. Authenticate Docker with AWS CLI

Before pushing, you need to log in to ECR:

# Get AWS credentials (if using IAM user)
aws configure

# Login Docker to ECR (macOS/Linux)
aws ecr get-login-password --region ap-south-1 | \
  docker login --username AWS --password-stdin \
  <your-aws-account-id>.dkr.ecr.ap-south-1.amazonaws.com

# Example output:
# Login succeeded

Windows PowerShell:

$ECR_TOKEN = aws ecr get-login-password --region ap-south-1
$ECR_URI = "<your-aws-account-id>.dkr.ecr.ap-south-1.amazonaws.com"
docker login --username AWS --password $ECR_TOKEN $ECR_URI

Troubleshooting:

3. Build Your Docker Image

Create a Dockerfile in your project root:

# Dockerfile
FROM node:18-alpine

WORKDIR /app

# Install dependencies
COPY package*.json ./
RUN npm ci --only=production

# Copy app code
COPY . .

# Expose port
EXPOSE 8080

# Start app
CMD ["npm", "start"]

Build the image:

docker build -t ecs-app:latest .

Check it works locally:

docker run -p 8080:8080 ecs-app:latest
# Visit: http://localhost:8080

4. Tag Image for ECR

You need to tag your image with ECR URI:

# Get ECR repository URI
ECR_URI="<your-aws-account-id>.dkr.ecr.ap-south-1.amazonaws.com/ecs-app-repository"

# Tag image
docker tag ecs-app:latest $ECR_URI:v1

# Example:
# docker tag ecs-app:latest 123456789012.dkr.ecr.ap-south-1.amazonaws.com/ecs-app-repository:v1

Multiple versions:

docker tag ecs-app:latest $ECR_URI:v2
docker tag ecs-app:latest $ECR_URI:latest

5. Push Image to ECR

docker push $ECR_URI:v1

# Expected output:
# The push refers to repository [123456789012.dkr.ecr.ap-south-1.amazonaws.com/ecs-app-repository]
# Try one more time...
# v1: pushing...
# Done!

Check in AWS Console:

1. Go to ECR → ecs-app-repository

2. Click "Images"

3. You should see: v1 (pushed 2 mins ago)

6. Configure ECS to Pull from ECR

In your ECS task definition (Part 3), add:

resource "aws_ecs_task_definition" "app" {
  family = "ecs-app-task"

  container_definitions = jsonencode([
    {
      name      = "ecs-app"
      image     = "${aws_ecr_repository.app.repository_url}:v1"
      memory    = 512
      portMappings = [
        {
          containerPort = 8080
          hostPort      = 8080
        }
      ]

      # ECR authentication (automatically handled)
      environment = [
        {
          name  = "NODE_ENV"
          value = "production"
        }
      ]
    }
  ])

  # Fargate profile
  capacityProviderStrategy = [
    {
      capacityProvider = "FARGATE"
      weight           = 1
    }
  ]
}

Common Errors & Fixes

Summary

You now have your Docker image in AWS ECR:

• ✅ ECR repository created (Terraform)

• ✅ Docker authenticated with AWS

• ✅ Image built, tagged, and pushed

• ✅ ECS configured to pull from ECR

Next Step: Part 3 will deploy the ECS Fargate cluster with Terraform.
